Our Bale Cutter is specially designed to cut all types of polymer bales quickly and safely perfect for rubber and related industries. Whether you’re handling tough, dense bales or need a machine that’s safe and easy to use, our Bale Cutter delivers.
| Technical specifications | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Bale dimensions (L x W X H in mm) |
Maximum 1000 x 600 x 300 |
||||||||||
|
Cutting speed |
10 cuts / min |
||||||||||
|
Knife |
Material – HCS hardened tempered cutting blade length 30 inches width 4 inches thickness 25mm |
||||||||||
|
Cutting block |
UHMW |
||||||||||
|
Feeding conveyor |
Bed / Roller |
||||||||||
|
Ram type |
Hydraulic |
||||||||||
|
Model |
Automatic / Manual |
||||||||||
|
Safety |
Double hand control / Fencing around the machine |
||||||||||
|
Machine dimension (L x W X H in mm) |
1500 x 100 x 2000 |
||||||||||
|
Machine weight in kg |
~600 |
||||||||||
|
Compressed air |
5 Bar (Minimum) |
||||||||||
|
Power supply |
3 Phase / 415 VAC |
||||||||||
|
Optional items |
Rubber bale lifting system (Vacuum) |
||||||||||
